Automatic Passive Component Analyzer Tool Features Automatic component identification Automatic test frequency selection (DC, 1kHz, 15kHz and 200kHz) Delayed or instant analysis (for hands free operation) Auto power-off Probe and test lead compensation Interchangeable probe sets Automatic ranging and scaling 1% basic accuracy for resistors 1.5% basic accuracy for inductors and capacitors Specifications Specification Summary at 20C (68F) unless otherwise specified Resistance: Range: 1Ohm to 2MOhm Resolution: 0.3Ohm Accuracy: A 1.0% A 1.2Ohm Capacitance : Range: 0.5pF to 10000AmicroF Resolution: 0.2pF Accuracy: A 1.5% A 1.0pF Inductance: Range: 1AmicroH to 10H Resolution: 0.4AmicroH Accuracy: A 1.5% A 1.6AmicroH Peak test voltage across O/C: -1.05V to 1.05V Peak test current into short circuit: -3.25mA to 3.25mA Test frequency accuracy: -1.5% to 1.5% Sine purity: -60dB 3rd harmonic Operating temperature range: 10C to 40C (50F to 104F) Battery operating voltage: 8.5V to 13V Weight per product (net.): 0.098kg (3.5oz) Dimensions per product : 103 x 70 x 20 mm (4.1" x 2.8" x 0.8")
|
