Orange 18AWG Stranded Hook-up Wire 100' UL1007NOTICE: The single rated wire is being replaced by the dual rated wire (P/N: 2171920) to support a wider temperature range up to 105C and lower cost. Features Single rated: UL1007 Temperature Range: -40C to 80C Peak Voltage: 300 Tin-plated copper PVC insulation Length (feet): 100 Stranded Wire Color: Orange AWG Wire Gauge: 18 Nominal Outside Diameter (inches): 0.08 16 strands of wire @ 30 AWG each Approvals: UL1007, VW-1, CSA-TR-64 90C, OSHA acceptable, RoHS Appliance Wiring Material (AWM) is UL recognized covering of insulated wire and cable intended for internal wiring of appliances, meters, panels, electrical and electronic equipment.
|
