20A 12V Power Redundancy Module 32mm DIN Rail Mount Features Supports 11 and N1 redundancy system 2 channels input and 1 output Suitable for redundancy operation of 12V systems Output current up to 20 amps Cooling by free air convection 60C derating) 32mm slim width Built-in 2 channels DC OK signal and alarm relay contact Installed on DIN rail TS35/7.5 or TS35/15 3 year warranty Specifications Output: 0 to 20A, continuous Capacitance: 320AmicroF (typ.) Number of Inputs: 2 channels DC Normal Voltage: 12 VDC DC Voltage Range: 9 to 14 VDC Rated Current: 0 to 10 A x2 input; 0 to 20 A x1 input Continuous Screw terminal blocks for input and output Size: 1.26"W x 4.93"H x 4.02"D (32 x 125.2 x 102 mm) Agency Approvals: UL, CUL, CB, CE, EN, EAC Applications Industrial control systems Semiconductor fabrication equipment Factory automation Electromechanical apparatus
|
