3000W Enclosed Single Output Power Supply 400V 7.5A Output: 400 Volts DC @ 7.5 Amps High Voltage DC (HVDC) Output Power Supply Solutions. Features AC input range: 180 to 264 VAC Built-in active PFC function Forced air cooling by built-in DC fans Output voltage / current programmable Active current sharing up to 9000W (21) Supports parallel function Built-in remote ON-OFF control, auxiliary power, and power OK signal Protections: Short circuit, overload, over voltage, over temperature, and fan failure Conformal coating 5 year warranty Agency Approvals: UL, CUL, CB, CE, EAC, DEKRA, CQC Specifications Output Voltage: 400 VDC Rated Current: 7.5 A Rated Power: 3000 W (3kW) Input Voltage Range: 180 to 264 VAC @ 47 to 63 Hz Size: 10.9"L x 7.0"W x 2.5"H (2U) High efficiency up to 93% (@ 230 VAC) Aux. Power: 12V @ 400 mA Applications Factory control or automation apparatus Test and measurement instruments Laser-related machines UV curing equipment Fish lamps Burn-in facilities
|
