Keyestudio MEGA Sensor Shield V1 MEGA (Arduino-Compatible) Have you had to deal with any of these issues When connecting a few of sensor modules to the MEGA 2560 control board, the power output connections aren't always enough, necessitating the use of a breadboard, which is a pain to wire. It is completely compatible with the MEGA 2560 control board, allowing you to stack the MEGA sensor shield on top of it with ease. The shield has 3PIN (G V S) digital and analog interfaces, making it simple to connect 3PIN sensor modules. It also includes 2.54mm pin pitch communication pins for serial and SPI connectivity. It comes with a reset button and 2 signal indicators as well. Note: for the 3PIN interface, the voltage of Analog pins (labeled V) is 5V; while the voltage of Digital pins (labeled V) is VCC, that is, the voltage input via a blue terminal block, default by jumper connected, connecting the voltage to 5V on the shield. Features Can be plugged into the MEGA 2560 control board Comes with a Reset button Comes with a power led and a D13 indicator Extends the digital and analog interface of MEGA into 3PIN Comes with a serial communication interface Extends an ICSP interface Extends a SPI interface Extends a URF01 interface Extends an APC220 interface Able to supply the voltage to sensor modules via the terminal block (jumper cap off) Dimensions: 100mm x 54mm Weight (only MEGA sensor shield): 39.2g Resources & Downloads WIKI page tutorial
|
