Pmod BT2: Bluetooth Interface Module The Pmod BT2 is a powerful peripheral module employing the Roving Networks RN-42 to create a fully integrated Bluetooth interface. Users can communicate with the chip via UART and can also use the secondary SPI header on the board for updating the RN-42 firmware if needed. Note: The Pmod BT2 is also featured in a fantastic product bundle, the Zybo Pmod Pack! This bundle was designed to expand project possibilities by utilizing a variety of peripheral modules perfectly suited for the Zybo Zynq-7000 FPGA. Features Bluetooth 2.1/2.0/1.2/1.0 compatible Add wireless capability with this low power, Class 2 Bluetooth radio Supports HID profile for making accessories such as pointing devices, etc. Secure communications, 128-bit encryption Six different modes Small PCB size for flexible designs 1.5" 0.8" (3.8 cm 2.0 cm) 12-pin Pmod connector with UART interface Shipping Contents Pmod BT2 Digilent custom antistatic Pmod packaging Resources & Downloads Resource Center (off-site) Reference Manual (off-site) Schematic
|
