Pmod SSR: Solid State Relay Electronic Switch Module The Pmod SSR is a solid-state relay that features IXYS' CPC1908J. The Pmod SSR uses a switch controlled by a single GPIO pin and is rated to block up to 48 Volts and switch up to 6 Amps (rms) continuous current. Features 0-48 V blocking voltage Can switch up to 6 Arms continuous current 2500 V input/output isolation Low on resistance with fast turn on/off Onboard LED to indicate on/off state Onboard terminal block for easy wire connection Small PCB size for flexible designs 1.7" 0.8" (4.3 cm 2.0 cm) 6-pin Pmod Connector with GPIO interface Follows the Digilent Pmod Interface Specification Type 1 Libraries and example code available in resource center Shipping Contents One Pmod SSR Digilent cardboard packaging with protective foam Resources & Downloads Resource Center (off-site) Reference Manual (off-site) Schematic
|
