Pmod GYRO: 3-axis Digital Gyroscope Module The Pmod GYRO is a 3-axis gyroscope powered by the ST Microelectronics L3G4200D. By communicating with the chip through SPI or IA2C, users may configure the module to report angular momentum at a resolution of up to 2000 dps at an output rate up to 800Hz. Features 3-axis MEMS digital gyroscope with high shock survivability Get angular velocity data with user selectable resolution (250/500/2000 dps) Two customizable interrupt pins User configurable signal filtering Power-down and Sleep modes Small PCB size for flexible designs 1.0 in 0.8 in (2.5 cm 2.0 cm) 12-pin Pmod connector with SPI interface and additional IA2C interface Library and example code available in resource center Shipping Contents One Pmod GYRO Custom Digilent antistatic Pmod packaging Resources & Downloads Resource Center (off-site) Reference Manual (off-site) Schematic
|
