Pmod CAN: CAN 2.0B Controller with Integrated Transceiver Module The Pmod CAN is a CAN 2.0B controller with an integrated transceiver. The embedded Microchip MCP25625 chip connects directly to the physical CAN bus and meets automotive requirements for high-speed (1 Mb/s), low quiescent current, electromagnetic compatibility, and electrostatic discharge. Features CAN 2.0B controller with integrated transceiver Suitable for automotive applications Up to 1 Mb/s operation Up to 10 MHz SPI clock speed Standard DB9 connector for secure connection Small PCB size for flexible designs 1.4" 1.8" (3.6 cm 4.6 cm) 12-pin Pmod connector with SPI interface Follows the Digilent Pmod Interface Specification 1.1.0 type 2A Libraries and example code available in resource center Shipping Contents One Pmod CAN Custom Digilent antistatic Pmod packaging Resources & Downloads Resource Center (off-site) Reference Manual (off-site) Schematic
|
