Pmod TMP2: Temperature Sensor Module The Pmod TMP2 is an ambient temperature sensor powered by the Analog Devices ADT7420. Through the I2C interface, users may appreciate a resolution of 0.00787C through 16 bits of data. Features 16-bit ambient temperature sensor Typical accuracy better than 0.25C 240 ms continuous conversion time Programmable over and under-temperature control pins No calibration required Small PCB size for flexible designs 1.0" 0.8" (2.5 cm 2.0 cm) 24-pin connector with I2C interface Follows Digilent Pmod Interface Specification Library and example code available in resource center Shipping Contents One Pmod TMP2 Custom Digilent antistatic Pmod packaging Resources & Downloads Resource Center (off-site) Reference Manual (off-site) Schematic
|
