Pmod ALS: Ambient Light Sensor Module The Pmod ALS demonstrates light-to-digital sensing through a single ambient light sensor. Digilent Engineers designed this Pmod around Texas Instrument's ADC081S021 analog-to-digital converter and Vishay Semiconductor's TEMT6000X01. Note: The Pmod ALS is also featured in a fantastic product bundle, the Zybo Pmod Pack! This bundle was designed to expand project possibilities by utilizing a variety of peripheral modules perfectly suited for the Zybo Zynq-7000 FPGA. Features Simple ambient light sensor Convert light to digital data with 8-bit resolution Small PCB size for flexible designs 0.8 in 0.8 in (2.0 cm 2.0 cm) 6-pin Pmod connector with SPI interface Follows Digilent Pmod Interface Specification Type 2 Shipping Contents One Pmod ALS Custom Digilent antistatic Pmod packaging Resources & Downloads Resource Center (off-site) Reference Manual (off-site) Schematic
|
