Pmod VGA: Video Graphics Array Module The Pmod VGA provides a VGA port to any board with Pmod connectivity. The VGA port can be used to drive standard displays such as televisions and monitors. The host board must be capable of driving a fast parallel data bus to properly drive a display with the Pmod VGA. Note: The Pmod VGA is also featured in a fantastic product bundle, the Arty S7 Pmod Pack! This bundle was designed to expand project possibilities by utilizing a variety of peripheral modules perfectly suited for the Arty S7 FPGA. Features Standard VGA port for connecting commonly found displays 12-bit RGB444 color depth Simple, high-speed R-2R resistor ladder DAC High-speed buffers support pixel clocks up to 150 MHZ Small PCB size for flexible designs 1.7" x 1.7" (4.3 cm 4.3 cm) Dual 12-pin Pmod connector with GPIO interface Follows Digilent Pmod Interface Specification Library and example code available in resource center Shipping Contents One Pmod VGA Custom Digilent antistatic Pmod packaging Resources & Downloads Resource Center (off-site) Reference Manual (off-site) Schematic
|
