Pmod SSD: Seven-segment Display Module The Pmod SSD is a two-digit seven-segment display. Users can toggle through GPIO signals which digit is currently on at a rate of 50 Hz or greater to achieve persistence-of-vision to give the effect of both digits being lit up simultaneously. Note: The Pmod SSD has two separate 6-pin headers. Features Two-digit high-brightness seven-segment display Easily view a counter or timer Common Cathode configuration Small PCB size for flexible designs 1.0" x 1.7" (2.5 cm 4.3 cm) Two 6-pin Pmod connectors with GPIO interfaces Follows Digilent Pmod Interface Specification Type 1 Shipping Contents One Pmod SSD Custom Digilent antistatic Pmod packaging Resources & Downloads Resource Center (off-site) Reference Manual (off-site) Schematic
|
