Pmod TPH: 6-pin Test Point Header Module The Pmod TPH offers 6 external pin headers so that users can easily test the GPIO signals passing through each of the pins. Features 6 external test point headers Easily access and test signals passing through Small PCB size for flexible designs 1.0 in 0.8 in (2.5 cm 2.0 cm) 6-pin Pmod port with GPIO interface Follows Digilent Pmod Interface Specification Type 1 Shipping Contents One Pmod TPH Custom Digilent antistatic Pmod packaging Resources & Downloads Resource Center (off-site) Reference Manual (off-site) Schematic
|
