Pmod SWT: 4 User Slide Switches Module The Pmod SWT provides users with four slide switches for up to 16 different binary logic inputs to for the attached system board. Note: The Pmod SWT is also featured in a fantastic product bundle, the Arty S7 Pmod Pack! This bundle was designed to expand project possibilities by utilizing a variety of peripheral modules perfectly suited for the Arty S7 FPGA. Features 4 slide switches Add user input to host board or project Static binary logic input Small PCB size for flexible designs 1.3 in 0.8 in (3.3 cm 2.0 cm) 6-pin Pmod connector with GPIO interface Follows Digilent Pmod Interface Specification Type 1 Shipping Contents One Pmod SWT Custom Digilent antistatic Pmod packaging Resources & Downloads Resource Center (off-site) Reference Manual (off-site) Schematic
|
