High Frequency SMT Power Inductor Set 59P Series Designed for VRD & VRM 10.x and 11.x applications. Features Recommended for use with all major Voltage Regulator ICs High Current handling capability in the smallest footprint Up to 2 MHz operating frequency Extended operating temperature range: -40C to 125C Robust SMD package capable of handling the most aggressive SMT assembly process Recommended for use with Volterra's 3rd Generation Advanced Regulator Modules Tested and approved by Volterra Applications VRD and VRM 10.x and 11.x based designs Multi-Phase Voltage regulator designs Multi-Phase synchronous Buck Voltage Regulator designs. Low voltage, high current, high frequency, DC-DC voltage regulator modules (LVRMs). Server, Desktop, PDA, Graphics cards, Notebook computers, DDR, telecom switches and routers DC-DC converters, Battery powered devices, high current power supplies High Current NPUs in networking equipment Point-of-load Modules Contains 125 nH, 54 A Isat, 10.4 x 7 x 5 mm (10 pcs) 150 nH, 44 A Isat, 10.4 x 7 x 5 mm (10 pcs) 200 nH, 32 A Isat, 10.4 x 7 x 7 mm (9 pcs) 470 nH, 35 A Isat, 10.41 x 9.65 x 5.84 mm (10 pcs) 1000 nH, 32 A Isat, 13.21 x 11.94 x 7.6 mm (5 pcs) 800 nH, 22 A Isat, 10.49 x 9.52 x 5.21 mm (20 pcs) 25 nH, 90 A Isat, 7.62 x 7.49 x 4.96 mm (10 pcs) 50 nH, 81 A Isat, 7.62 x 7.49 x 4.96 mm (9 pcs) 70 nH, 65 A Isat, 7.62 x 7.49 x 4.96 mm (10 pcs) 100 nH, 46 A Isat, 7.62 x 7.49 x 4.96 mm (10 pcs) 200 nH, 76 A Isat, 13.21 x 11.94 x 7.60 mm (10 pcs) 320 nH, 50 A Isat, 13.21 x 11.94 x 7.60 mm (10 pcs) 500 nH, 46 A Isat, 13.21 x 11.94 x 7.60 mm (5 pcs) 500 nH, 46 A Isat, 13.21 x 11.94 x 11 mm (4 pcs) 470 nH, 19 A Isat, 8 x 7.7 x 4.25 mm (6 pcs) 200 nH, 28 A Isat, 8 x 7.7 x 4.57 mm (10 pcs)
|
