SDL1020X Programmable DC Electronic Loads 200 WSDL1000X/SDL1000X-E series Programmable DC Electronic Loads have a 3.5 inch TFT-LCD display, a user-friendly interface and superb performance specifications. SDL1020X DC Electronic Loads feature an input range of 150 V/30 A 200 W. The SDL1000X series leads with measurement resolution of 0.1 mV/0.1 mA and the base SDL1000X-E series resolution is 1 mV/1 mA and adjustable current rise times from 0.001 A/s2.5 A/s. For remote communication and control, the SDL series includes RS232/USB/LAN interface types. SDL1000X electronic loads deliver stability over a wide range of applications and can meet all kinds of testing requirements, including: Power, battery/handheld device design, industry, LED lighting, automotive electronics, and aerospace. Key Features Input voltage/current/power: 150 V/30 A 200 W Mode: CC/CV/CR/CP CC Dynamic mode frequency: 25 kHz Measuring speed: up to 500 kHz Current Slew Rate: 0.001 A/us2.5 A/us Min. readback resolution: 0.1 mV, 0.1 mA 4 static modes / Dynamic mode: CC/CV/CR/CP CC Dynamic mode: Continuous, pulsed, toggled CC Dynamic mode: 25 kHz, CP Dynamic mode: 12.5 kHz, CV Dynamic mode: 0.5 Hz Measuring speed of voltage and current: up to 500 kHz Short-circuit, Battery test, CR-LED mode, and factory test functions 4-wire SENSE compensation mode function List function supports editing as many as 100 steps Program function supports 50 groups of steps OCP, OVP, OPP, OTP and LRV protection External analog control Voltage, Current monitoring via 0-10 V 3.5 inch TFT-LCD display, capable of displaying multiple parameters and states simultaneously Built-in RS232/USB/LAN communication interface, USB-GPIB module (optional) Waveform trend chart and easy-to-use file storage and call functions Includes PC software: Supports SCPI, LabView driver Support and Resources Software (off-site) Firmware (off-site) Drivers (off-site) Scripts and Others (off-site) Documents (off-site) Operating Tips (off-site) Videos (off-site)
|
