Tunable Inductor 0.1 uH Shielded with Plastic Sleeve Features Number of Coils: 1 ; Inductance : 0.10 AmicroH (nominal) ; Inductance: 0.094 AmicroH to 0.11 AmicroH (min-max) ; DC Resistance (DCR): 124 mOhm Max ; Shielding: Shielded with plastic sleeve ; Operating Temperature: -40C to 85C ; Mounting Type: Through Hole ; Package: Radial ; Size: 0.300" L x 0.300" W (7.62 mm x 7.62 mm) ; Height: 0.460" (11.68 mm); pagebreak Overview This versatile Coilcraft variable inductor operates over a tuneable range of frequencies between 0.094 uH to 0.11 uH (0.1uH nominal). Coilcraft "Slot Seven" RF coils come in an international 7 mm package. Their precision-molded slotted bobbins ensure tight tolerances and high stability. All parts come with a metal can that provides electrostatic shielding. "Slot Seven" coils are tuned by means of slotted ferrite tuning cores for easy, positive adjustment. Use the Coilcraft Slot Tuner for a precise fit to the tuning slug.
|
